(I) Main performance and structural features

1. Dual frequency converter control, bag length is set and cut immediately, no need to adjust the empty run, one-step to save time and film.

2. Human-machine interface, parameter setting is convenient and fast.

3. Fault self-diagnosis function, fault display is clear at a glance.

4. High-sensitivity photoelectric eye color mark tracking, digital input sealing and cutting position, making the sealing and cutting position more accurate.

5. Temperature independent PID control, better suitable for various packaging materials.

6. Positioning stop function, no sticking knife, no waste of film.

7. The transmission system is simple, the work is more reliable, and the maintenance is more convenient.

8. All controls are implemented by software, which is convenient for function adjustment and technology upgrade, and never lags behind.

(II) Scope of application:

Food: small biscuits, rice cakes, candies, chocolates, egg pies, small cakes, oil corners and other regular small foods

Others: single small toys, cards, lighters, electrical tape, pens, data cables, electronic cigarette holders and other regular small products.

(IV) Technical specifications

Model 250B

Bag length 65-190 or 120-280

Bag width 30-120

Product height Max: 40mm

Packing speed 40-200 bags/min

Power supply specification 220V, 50/60HZ, 2.4KVA

Machine size (L) 3770×(W) 670×(H) 1450

Machine weight 600Kg

Remarks

The above parameters can be modified according to customer requirements and item requirements.
